# coordinate systems

These are the coordinate systems a 3D vertex is transformed thru:

Transformation of a 3D vertex thru coordinate systems:

local world eye perspective 2D view-port

Green indicates transformations done by engine.
Red indicates transformations done by gfx-sys.
Local:World and World:Eye can be combined by matrix multiplication.

## local coordinate system

3D objects have their own local coordinate system. Also known as object coordinates.

## world coordinate system

World coordinate system contains simulated world (scene to be rendered). It is mapped to eye coordinate system by eye matrix.

## eye coordinate system

Eye coordinate system stays mapped to view-port of window system. Eye vertexs are final result of all transformations, which are submitted to gfx-sys.

(X,Y) eye coordinates correlate to (X,Y) view-port coordinates. An eye Z coordinate measures distance from eye/view-point. For an eye vertex, (X,Y) are divided by Z to project vertex onto view-port (window). This projection creates illusion of perspective on a 2D computer display.

## perspective coordinate system

Eye coordinates are transformed by underlying graphics system into perspective coordinates. View frustrum (which exists in eye space) is mapped to perspective coordinates.

## view-port coordinate system

This is 2D window on computer's window system.

## normal coordinate system

A normal vector calculated by a cross product exists in its own coordinate system where its origin is one of vertexs on a polygon on which it is normal/perpendicular to.

# transpose matrix

A matrix maps one coordinate system to another. Mapping is directed. Mapping can be reversed by transposing a matrix. This is done by turning each row into a column. Note: transpose matrix and inverse matrix are different mathematical concepts.

``` [ Xx Xy Xz ]     [ Xx Yx Zx ]
[ Yx Yy Yz ]     [ Xy Yy Zy ]
[ Zx Zy Zz ]     [ Xz Yz Zz ]
```

An application of a transpose matrix is animated firing guns in a 1st-person view. Eye matrix maps world-to-eye coordinates. Tracer rounds from gun are modeled starting from a local coordinate system. What is needed is a local matrix that maps local-to-world coordinates and it must be aligned with eye matrix. Transpose of eye matrix can be used as local matrix. Although transposed eye matrix apparently maps eye-to-world coordinates, it will work as result of transformation is in world coordinates (on output side). Local coordinates are substituted for eye coordinates on input side. A copy of eye matrix used as local matrix would not work because two transformations from local-to-world and world-to-eye would nonsensically pass thru eye matrix (which is meant for latter transformation only).

# BSP trees

"BSP" usually refers to an AA-BSP tree.

## overview

Two kinds of BSP trees are axis-aligned and polygon-aligned (AA-BSP and PA-BSP). A BSP node has two child nodes metaphorically named left and right.

## axis-aligned BSP trees

Axis-aligned is much simpler and faster to construct than polygon-aligned. Axis-aligned is useful for containing 3D objects in rectangular volumes. Objects can be coarsely (imprecisely) sorted in back-to-front order by traversing an axis-aligned using distance between a partition vs. view-point as criteria for branching left or right. Granularity of sorting is rectangular volume of a BSP node. A BSP node may contain multiple Objects, but sorting (by BSP traversal) goes no further (this is why sorting isn't precise). Bypassing finely sorting Objects of a BSP node is possible if none of Objects are translucent. Rendering opaque objects out-of-order relies on hardware Z buffer. Note that purpose of sorting is to properly alpha-blend translucent Objects.

## polygon-aligned BSP trees

Polygon-aligned BSP trees are well-suited for precise collision-detection of objects having irregular shapes. Though they have disadvantages such as being complex and slow to construct. Polygons intersecting a plane must be split into two polygons.

## traversal path of BSP varies according to view-point

Key to understanding a BSP tree is that traversal path varies according to a branch condition and a stop condition. Unlike a regular binary tree, these conditions are variable. For example, when adding Objects, branch condition is whether an Object can fit inside a partition. When culling/sorting, branch condition is determined by distance and orientation of a partition relative to view-point

## culling and sorting objects by traversing

Culling and sorting objects are done simultaneously by traversing a BSP tree. Traversing is sorting. Reaching a stop condition that evaluates true is culling.

A BSP node and its descendants outside view frustum are culled since they won't be visible. This culling method is efficient, since a whole subtree of invisible objects are eliminated in one step.

To properly render translucent polygons, furthest-to-nearest order is necessary. During traversal, if two partitions are visible, partition that is furthest from view-point is selected. A partition's distance and whether inside frustrum are sub-conditions of branch condition. Target of traversal path is to reach smallest and most distant partition.

Branch condition determines which ways to branch:

```    If left is farther than right from view-point:
If left is facing, branch.
If right is facing, branch.
If right is farther than left from view-point:
If right is facing, branch.
If left is facing, branch.
```

Stop condition determines when to stop recursing:
if partition is not facing or partition is outside view frustrum.

Ignoring view frustrum for a moment, possibly all partitions or none will be visible. For example, if view-point is at corner of a partition and facing outwards, then none are visible. If view-point is rotated 180 deg, then all become visible.

## adding objects to a BSP Tree

Adding objects to a AA-BSP is similar to octrees. Tree is recursed until a node (corresponding to an octant) is found that object doesn't fit or maximum depth is reached, then object is attached to its parent node.

## objects which intersect a BSP Plane

There are several cases where an Object can intersect a BSP plane. One case is a Dyna that moves between any two partitions. Worst case is a very large Object that, besides intersecting one or more planes, overlays partitions in multiple BSP trees.

A way to solve intersection is to let multiple BSP nodes reference same Object in case Object occupies at least one partition that wasn't culled, but keep a flag (or frame number) to remember that Object was drawn in a frame in case one or more of its partitions are visible (to avoid redraw).

## collision-detection using a polygon-aligned BSP tree

Testing if a 3D vertex is inside a PA-BSP is done by traversing. If vertex is inside, then vertex will be behind every polygon encountered during traversal. Eventually, traversal will stop at a leaf node, which means a collision was detected.

# minimum distance between point and line segment

AB is line SEGMENT.
C is point to measure its distance from AB.

Shortest line from a point to a line is an orthogonal line. Orthogonal line intersects at a tangent. If orthogonal line were rotated in either direction, it would move off other line and would have to be increased to remain in intersection, thus it is has minimum distance.

```A-------------B
|
|
C
```

According to linear algebra, dot product can be used to compute a projection of vector onto another vector. In this case, projection of C onto AB.

```        AC . AB
t = --------------
||AB|| * ||AB||

DotProduct( AC, AB )
t = --------------------
DistanceSquared( B )  = DotProduct( AB, AB )
```

t is a scalar that can be used to compute point of intersection I:

```I = A + t * (B - A)
```

## computer implementation:

Goal is find minimum distance on a point on LINE SEGMENT. If intersection is outside LINE SEGMENT, then instead, compute distances between CA and CB and return minimum.

This C++ code is meant for testing/demonstration. It is implemented as a class/object as a lot of results are computed which are stored in data members (too complex for a function's return value).

## C++ code implementation:

(written by Jim Brooks)

```////////////////////////////////////////////////////////////////////////////////
///
class DistancePointLineSegment
{
public:
/*****************************************************************************
* This constructor is minimum distance function.
*****************************************************************************/
DistancePointLineSegment( const Vector2& a,
const Vector2& b,
const Vector2& c )
{
// AC and AB are vectors with A as origin.
// Compute orthogonal projection of C onto AB as scalar t.
const Vector2 ac( c - a );
const Vector2 ab( b - a );
mT = DotProduct( ac, ab )
/ DotProduct( ab, ab );

// If intersection is on line SEGMENT (within A..B),
// then t = {0,..,1}.
if ( (mT >= 0.0f) and (mT <= 1.0f) )
{
mIfIntersectsLineSegment = true;
mIntersection.x          = a.x + mT * (b.x - a.x);
mIntersection.y          = a.y + mT * (b.y - a.y);
mDistance                = Distance( mIntersection - c );
}
else
{
// Intersection is outside line SEGMENT.
// Instead, compute distances between CA and CB
// and return minimum.
mIfIntersectsLineSegment = false;
//mIntersection.x          = N/A
//mIntersection.y          = N/A
mDistance                = std::min( Distance( c-a ), Distance( c-b ) );
}
}

public:
bool        mIfIntersectsLineSegment;   ///< true if intersection on LINE SEGMENT (false if outside segment)
fp          mT;                         ///< always valid
Vector2     mIntersection;              ///< N/A if not mIfIntersectsLineSegment
fp          mDistance;                  ///< minimum distance between point C and line segment AB
};
```

Test results:
"intersection = " means intersection within line segment (not infinite line)

```----------------------------------------
Diagonal line from +Y to -X.  Midpoint/intersection is obvious.
line     = Vector2:(0,500) Vector2:(-500,0)
point    = Vector2:(0,0)
t        = 0.5
distance = 353.553
intersection = Vector2:(-250,250)
----------------------------------------
Horizontal line that spans -X..+X.  Intersection is obvious.
line     = Vector2:(-50,50) Vector2:(50,50)
point    = Vector2:(0,0)
t        = 0.5
distance = 50
intersection = Vector2:(0,50)
----------------------------------------
Diagonal thru origin.
line     = Vector2:(-50,50) Vector2:(100,-100)
point    = Vector2:(0,0)
t        = 0.333333
distance = 0
intersection = Vector2:(0,0)
----------------------------------------
Diagonal aiming at origin but halfway there.
line     = Vector2:(-50,50) Vector2:(-25,25)
point    = Vector2:(0,0)
t        = 2
distance = 35.3553
intersection = none
----------------------------------------
Diagonal aiming at origin but halfway there (swap a,b).
line     = Vector2:(-25,25) Vector2:(-50,50)
point    = Vector2:(0,0)
t        = -1
distance = 35.3553
intersection = none
----------------------------------------
Directly aims at origin but does not quite reach.
line     = Vector2:(-50,-50) Vector2:(-0.1,-0.1)
point    = Vector2:(0,0)
t        = 1.002
distance = 0.141421
intersection = none
----------------------------------------
Directly aims at origin but does not reach (swap a,b).
line     = Vector2:(-0.1,-0.1) Vector2:(-50,-50)
point    = Vector2:(0,0)
t        = -0.00200401
distance = 0.141421
intersection = none
----------------------------------------
Skewed above origin towards NE.
line     = Vector2:(-100,10) Vector2:(100,500)
point    = Vector2:(0,0)
t        = 0.0539093
distance = 96.3637
intersection = Vector2:(-89.2181,36.4156)
```

References:
- "Linear Algebra", Tom Apostol
- comp.graphics.algorithms FAQ

# line-plane intersection

This requires thinking in terms of algebra and finding value of a variable. Known is a plane defined by its position and its normal vector. And known is a line segment defined by two vectors for its end points.

Thinking logically, there is a point on line that has to intersect plane (ignore other cases for now). Idea is that there is a distance from line's beginning to its end. If a line's normalized direction is multiplied by this distance, that produces line's end-point. Likewise, a line's normalized direction can be multiplied an unknown variable `d` which can produce line's point of intersection with plane.

## C++ code implementation:

(written by Jim Brooks)

```/*******************************************************************************
*
*******************************************************************************/
bool IntersectionPlaneLine(       Vector3& intersection, // OUT
const Vector3& planePos,
const Vector3& planeNormalVector,
const Vector3& lineBegin,
const Vector3& lineEnd )
{
// Based on:
// Algrebraic form
// https://en.wikipedia.org/wiki/Line-plane_intersection
// doc/html/math/linePlaneIntersection.html
//
// Idea is to find value of factor d
// which can be used to multiplied line direction (distance from line)
// to a point on line that intersects plane.
//
// Express plane as equation:
// (p - p0) . n = 0
// n is plane's normal vector
// p0 is a given point on plane
// p is a variable to be solved, in this case, point of intersection
//
// p = d*l + l0
// l is a direction vector of line
// l0 is a point on line
// In this C++ function
// ld = Normalize( lineEnd - lineBegin )
// l0 = lineBegin
//
// Substitute line into plane equation:
// ((d*l + l0) - p0) . n = 0
//
// Distribute n:
// d*l . n + (l0 - p0) . n = 0
//
// Solve for d (line factor):
//     (p0 - l0) . n
// d = -------------
//         l . n
//
// If line is parallel and outside plane: 0 / non-zero
// If line is parallel and on plane     : 0 / 0
// Else intersection and d represents distance along line from l0

const Vector3& p0 = planePos;               // alias for math
const Vector3& l0 = lineBegin;              // alias for math
const Vector3& n  = planeNormalVector;      // alias for math
const Vector3  l  = Normalize( lineEnd - lineBegin );  // line direction, unit

const fpx numerator   = DotProduct3( p0 - l0, n );
const fpx denominator = DotProduct3( l, n );

if ( ABS(denominator) < 0.0001 )
{
return false;
}
else
{
const fpx d = numerator / denominator;
intersection = lineBegin + (l * d);
return true;
}
}
```

References:
https://en.wikipedia.org/wiki/Line-plane_intersection
http://paulbourke.net/geometry/planeline/

# collision detection

For small objects, simple calculations based on bounding box or spheres should suffice.

For objects that are large and have irregular shapes, polygon-aligned BSP trees are necessary to accurately detect collisions. If collider is a small object and its rate of translation is fine enough, a simple point intersection test of collidable's BSP tree should suffice.
